Neo Impex Stainless Pvt. Ltd. has an ever expanding portfolio of brilliant products that have been engineered through our understanding of client expectation and his industry requirement. We only do what is right for your business. We are manufacturers, suppliers and exporters of Piggable Bends that are fundamental to join pipes of different diameters. Our Stainless Steel Piggable Bends have excellent mechanical properties at both cryogenic and elevated temperatures, whereas our ASME B16.9 Piggable Pipe Bends are resistant to a number of corrosives, including caustic alkalies and sulphuric acids, thus they connect pipes conveying caustic fluids. Our ANSI B16.9 Piggable Bends can be bent into various angles to fit a pipe. We offer Piggable Bends in various thicknesses, in seamless, welded and fabricated types and schedules and ranges that comply with ANSI standards.
What are ANSI B16.9 Piggable Bends?
ANSI B16.9 Piggable Bends are pipe fittings used in pipelines that allow pipeline-cleaning pigs to pass through. They are made to meet industry standards for pressure-temperature ratings, dimensions, tolerances, materials, marking & testing requirements.
What is the Purpose of Piggable Bends?
The purpose of piggable bends is to allow pipeline-cleaning pigs to pass through to clean and inspect pipelines without dismantling the entire pipeline. This helps to maintain the integrity & efficiency of the pipeline by removing debris, sediment, and other contaminants that can build up over time.
How are piggable bends different from regular pipe bends?
Piggable bends are different from regular pipe bends in that they are designed to allow pipeline-cleaning pigs to pass through. They have a larger radius and a smoother flow path to accommodate the pigs and are made to meet industry standards for pressure-temperature ratings, dimensions, tolerances, materials, marking, and testing requirements.
How are ANSI B16.9 piggable bends installed?
ANSI B16.9 piggable bends are installed using a standard butt-welding process. The ends of the bend are beveled to match the thickness & angle of the pipes being connected. The pipes are then welded to the pluggable bend using a welding machine to create a strong, leak-proof joint. Before installation, the pipeline must be properly cleaned and inspected to ensure it is free from debris and other contaminants that could damage the pigs or the pipeline.
Dimensions : ASME/ANSI B16.9, ASME B16.28, MSS-SP-43
Size : 2"NB TO 18" NB
Type : Seamless / ERW / Welded / Fabricated
Bend Radii : 75 / 100 / 150 / 250 / 300 / 500 / 800 / 1,000 / 1,200 / 1,500 mm
Bending Radius(R): R=1D, 2D, 3D, 5D, 6D, 8D, 10D or Custom
Bending angle (θ): 15°, 30°, 45°, 60°, 90°, 135°, 180°
Stainless Steel Piggable Bend :
ASTM A403 WP316/316L, ASTM A403 SA / A 774 WP-S, WP-W, WP-WX 304/304L, ASTM A182 F316L, 304L, DIN 1.4301, DIN1.4306, DIN 1.4401, DIN 1.4404
Duplex & Super Duplex Steel Piggable Bend :
ASTM A 815, ASME SA 815 UNS NO S31803, S32205. UNS S32750, S32950. Werkstoff No. 1.4462
Carbon Steel Piggable Bend :
ASTM A234, ASME SA234 WPB , WPBW, WPHY 42, WPHY 46, WPHY 52, WPH 60, WPHY 65 & WPHY 70.
Low Temperature Carbon Steel Piggable Bend : ASTM A420 WPL3, A420 WPL6
Alloy Steel Piggable Bend :
ASTM / ASME A/SA 234 Gr. WP 1, WP 5, WP 9, WP 11, WP 12, WP 22, WP 91
Nickel Alloy Piggable Bend :
ASTM B336, ASME SB336, Nickel 200 (UNS No. No2200), Nickel 201 (UNS No. N02201), Monel 400 (UNS No. N04400), Monel 500 (UNS No. N05500), Inconel 800 (UNS No. N08800), Inconel 825 (UNS No. N08825), Inconel 600 (UNS No. N06600), Inconel 625 (UNS No. N06625), Inconel 601 (UNS No. N06601), Hastelloy C 276 (UNS No. N10276), Alloy 20 (UNS No. N08020), Titanium (Grade I & II), Cupro-Nickel 70/30, CuNi10Fe1Mn, CuNi30Mn1Fe.
|Buttweld Piggable Bend||Butt Weld Piggable Pipe Bends|
|ASME B16.9 Piggable Bend||90 Degree Piggable Bend|
|Stainless Steel Piggable Bend Suppliers||SS Piggable Bends|
|ANSI B16.9 Piggable Pipe Bend Dealer||ASME B16.28 Buttweld Piggable Bend Exporter|
|Welded Piggable Bend Stockholder||Seamless Piggable Bend Distributors|
|Carbon Steel Piggable Bends||High Quality Piggable Bend Manufacturer|
|ASTM A403 Stainless Steel Piggable Bends||Duplex Steel Piggable Bends|
|Super Duplex Steel Piggable Bend||Copper Nickel Piggable Bends|
|High Nickel Alloy Piggable Bend||Hastelloy Piggable Bend Stockist|
|Titanium Piggable Bend||Inconel Butt weld Piggable Bend|
ASME B16.9 Piggable Bend are known to deliver exceptional performance and are generally developed for meeting the demands. We offer a broad range of Buttweld Piggable Bends through a worldwide network of stock-keeping branches. These Piggable Pipe Bend is use in various industries like :
We are renowned & most acclaimed Source, Stock, Distribution, Manufacturer, Suppliers, Stockholder, Traders, Wholesaler, Dealer, Distributor, Importer & Exporter, Fabricator, Stockist of Butt Weld Piggable Bends in Stainless Steel.
