LTCS A420 WPL6 Buttweld Fittings

SA 420 WPL6 Elbow, Low Temperature Carbon Steel WPL6 Butt weld Pipe Fittings, LTCS ASTM A420 WPL6 Pipe Fittings, Stockist of Low Temperature A420 Gr. WPL6 Buttweld Pipe Fittings, Low Temperature WPL6 Elbow Dealer in India, Global Supplier of A420 LTCS WPL6 Butt weld Pipe Fittings.

LTCS ASTM A420 WPL6 Buttweld Fittings

Low Temperature Carbon Steel A420 WPL6, also known as Buttweld Fittings, are mainly used in lower temperature pressure vessels and equipment. LTCS A420 WPL6 Buttweld Fittings are available in a variety of diameters and thicknesses and provide a strong connection between two pieces of pipeline. They can be either seamless or welded. These include a420 wpl6 chemical composition, tensile strength, yield strength, wall thickness, and elongation. Low Temperature Carbon Steel A420 WPL6, or Buttweld Pipe Fittings, are a great choice for a wide variety of applications. Low temperature carbon steel A420 buttweld pipe fittings can be used in any number of applications, including gas pipelines. These fittings are available in a variety of sizes and shapes to fit different pipe sizes.

ANSI B16.9 Low Temperature Steel Reducer, LTCS A420 Buttweld Fitting, Low Temperature A420 WPL6 Buttweld Pipe Fittings, Low Temperature Carbon Steel ASTM A420 WPL6 Fittings, ANSI B16.9, ANSI B16.28, MSS SP-43, or MSS SP-79 LTCS WPL6 Butt weld Pipe Fitting, Low Temperature Carbon Steel Welded Fittings, Manufacturer Of ASTM A420 WPL6 LTCS Buttweld Fittings in Mumbai, India.

With ISO certification, Neo Impex Stainless Pvt. Ltd. abides by the principles of quality and safety, being disciplined and dedicated to precision. We are manufacturers, suppliers, and exporters of LTCS A420 WPL6 Buttweld Fittings compliant with ASTM A420 specifications, which demand wrought carbon steel and alloy steel pipe fittings that are seamless as well as welded and are amenable in the pressure piping services but at low temperatures. Our LTCS A420 WPL6 Buttweld Concentric Reducers are the preferred choice in oil and crude petroleum wells as they can progress effortlessly between pipes having different diameters under low pressure. They readily allow the passage of slurries and toxic liquids.

ASTM A420 wpl6 buttweld pipe fittings, Best Price of WPL6 Low Temperature Carbon Steel Pipe Cap Exporter, LTCS Grade WPL6 Pipe Elbow, Stockholder Of LTCS A420 WPL6 Tee, ASME SA420M Low Temperature Steel WPL6 Stub End Wholesaler, LTCS WPL6 Pipe Fitting, LTCS WPL6 Seamless Pipe Fittings Traders in India.

We supply LTCS A420 WPL6 Buttweld Pipe Elbow and High Yield CS A860 Buttweld Fittings to the beverage and compressed gas industrial units as they can clamp a pipe to shield it against wear and tear. Also, We offer a wide range of Low-Temperature Carbon Steel ASTM A420 WPL6 pipe fittings such as LTCS tee, WPL6 LTCS End Pipe Cap, ASTM A420 WPL6 LTCS reducer, A420 WPL6 Low-Temperature Carbon Steel cross, Low-Temperature Carbon Steel A420 WPL6 elbow, LTCS WPL6 stub ends, etc.

Standard Specification For LTCS ASTM A420 WPL6 Pipe Fittings


Specifications : ASTM A420 / ASME SA420

Dimensions : ASME/ANSI B16.9, ASME B16.28, MSS-SP-43

Size : 1/8” NB TO 48” NB. (Seamless & 100% X-Ray Welded, Fabricated)

Type : Seamless / Welded / Fabricated

Bending Radius : R=1D, 2D, 3D, 5D, 6D, 8D, 10D or Custom

Grades : A420 WPL3 / A420 WPL6

Thickness : Sch 5s, Sch 10s, Sch 40s, Sch 80s, Sch 160s, Sch XXS


ASTM A420 WPL6 Fittings Equivalent Grades


Material Fttg Valves Flg Pipes Bolts and Nuts
Low Temperature Carbon Steel
Alloy
Low-Temp
A420 Gr WPL6 A352 Gr LCB A350 Gr LF2 A333 Gr 6 A320 Gr L7
A194 Gr 7
A420 Gr WPL3 A352 Gr LC3 A350 Gr LF3 A333 Gr 3

LTCS ASTM A420 WPL6 Pipe Fittings

Seamless/ Welded 100% Radiography Tested

Products Size
LTCS ASTM A420 WPL6 Elbow – Long Radius LTCS ASTM A420 WPL6 Stub Ends Sizes 1/2″ – 48″
LTCS ASTM A420 WPL6 Elbow – Short Radius LTCS ASTM A420 WPL6 Cross
LTCS ASTM A420 WPL6 Reducing Elbow LTCS ASTM A420 WPL6 Reducing Cross
LTCS ASTM A420 WPL6 45° Elbow LTCS ASTM A420 WPL6 Tees
LTCS ASTM A420 WPL6 Fabricated Tee LTCS ASTM A420 WPL6 End Cap
LTCS ASTM A420 WPL6 Reducer LTCS ASTM A420 WPL6 Seamless Fittings
LTCS ASTM A420 WPL6 Concentric Reducer LTCS ASTM A420 WPL6 Pipe Nipple
LTCS ASTM A420 WPL6 Eccentric Reducer LTCS ASTM A420 WPL6 5D Elbow
LTCS ASTM A420 WPL6 3D Elbow LTCS ASTM A420 WPL6 Welded Pipe Fittings

ASTM A420 WPL6 Chemical And Physical Properties

Grade C Mn P S Si
ASTM A420 WPL6 Fittings 0.3 0.60-1.35 0.035 0.04 0.15-0.30

ASTM A420 Gr. WPL6 Mechanical Properties Chart

Tensile Requirements ASTM A420 WPL6 Fittings
Tensile Strength
min, ksi [MPa]
60-85[415-585]
Yield Strength
min, ksi [MPa]
35[240]

Various Size & Schedules of LTCS A420 WPL6 Pipe Fittings

  ASTM A420 WPL6 ButtWeld Pipe Fittings
Schedules Sch 10S - 80S
SA 420 WPL6 Fittings Types 90º Long radius, SA420M WPL6 90º SRs, 45º Elbows,
Concentric Reducers, Eccentric Reducers,
Low Temp. Carbon Steel Tees, Reducing Tees and Stub Ends Fittings
Sizes 1/2" – 12"

Types Of Low Temperature Carbon Steel Buttweld Pipe Fittings



Low Temperature Carbon Steel Fittings Pressure Ratings


Temp. -20~100 150 200 300 400 500
*MAS 17.1 17.1 17.1 17.1 17.1 17.1
Temp. 600 650 700 750 800 850
*MAS 17.1 17.1 15.6 13.0 10.8 8.7

ASTM A420 WPL6 Buttweld Pipe Fittings Dimensions Schedule

Nom. Pipe Size ASTM A420 Carbon Steel 90° Elbows ASTM A420 Carbon Steel 45° Elbows ASTM A420 Carbon Steel 180° Return Long Radius
Long Radius Short Radius 3R Long Radius 3R STD XS
STD XS SCH. 160 XXS STD XS STD XS STD XS STD XS
½ .18 .25 .09 .19 .35
¾ .19 .25 .09 .19 .40 .65
1 .40 .50 .60 .75 .25 0.25 .31 .75 1.00
.60 .90 1.00 1.38 .4 0.38 .50 1.25 1.75
.90 1.15 1.80 1.50 .56 .75 .40 .69 1.88 2.39
2 1.60 2.20 3.25 3.50 1.00 1.50 3.00 4.00 .81 1.19 1.5 2.1 3.23 4.40
3.25 4.00 5.13 7.00 2.13 2.80 6.00 8.00 1.75 2.13 3.00 4.00 6.50 8.00
3 5.00 6.50 8.50 11.0 3.00 4.25 10.0 13.0 2.63 3.50 5.00 7.00 10.25 13.00
6.75 8.35 16.0 4.50 6.00 13.0 18.0 3.50 4.50 7.00 9.00 13.00 16.75
4 9.00 13.5 18.0 20.0 6.25 8.50 18.0 25.0 4.50 6.10 9.00 13.0 18.5 25.0
5 15.0 22.0 32.0 36.0 9.60 14.0 29.0 43.0 7.50 10.7 15.0 22.0 30.0 44.0
6 24.5 35.0 57.0 65.0 18.0 23.0 45.0 70.0 12.0 17.5 23.0 35.0 50.0 70.0
8 50.0 71.0 120 118 34.0 47.5 90.0 140 23.0 35.0 45.0 70.0 95.0 142
10 88.0 107 260 58.0 70.0 159 218 43.0 53.0 80.0 109 117 215
12 125 160 450 80.0 104 233 310 62.0 84.0 117 155 230 320
14 160 205 572 105 140 298 400 80.0 100 149 200 325 400
16 206 276 132 174 390 520 100 135 195 260 412 550
18 260 340 167 219 495 660 126 167 248 330 510 690
20 320 420 210 275 610 810 160 206 305 405 640 830
22 394 520 735 980 197 260 368 490 787 1040
24 460 600 298 392 875 1170 238 300 438 585 890 1200
26 550 729 1030 1370 275 365 515 685
30 734 975 1370 1830 367 488 685 915
36 1062 1412 1970 2630 531 706 985 1315

Low Temperature Carbon Steel ASTM A420 WPL6 Buttweld Fittings Available Types

Low Temperature Carbon Steel Pipe Fittings LTCS WPL6 Buttweld Pipe Fittings
LTCS A420 WPL6 Seamless Pipe Fittings LTCS A420 Welded Pipe Fittings
LTCS A420 WPL6 Pipe Elbow Low Temperature Buttweld Tee
LTCS Buttweld Reducer Suppliers ANSI WPL6 LTCS Pipe Fittings
Carbon A420 WPL6 Stubends Dealer ASTM A420 WPL6 Pipe Fittings Exporter
LTCS WPL6 Butt weld Fittings Stockholder Steel WPL6 Pipe End Cap Distributors
Low Temperature Carbon Steel WPL6 45deg.Elbow A420 WPL6 90deg. LR Elbow Manufacturer
LTCS Grade WPL6 Pipe Tee Low Temperature Carbon Steel ASTM A420 WPL6 Cross
Low Temperature CS WPL6 Butt weld Reducing Nipple Carbon WPL6 Short Radius Elbow
ANSI B16.9 ASTM A420 WPL6 Buttweld Fitting A420 WPL6 End Pipe Cap Stockist
ASTM A420 WPL6 Welded Pipe Fittings LTCS ASME SA420 WPL6 Pipe Fittings

LTCS WPL6 Buttweld Pipe Fittings Application

LTCS ASTM A420 WPL6 Pipe Fittings are known to deliver exceptional performance and are generally developed for meeting the demands. We offer a broad range of LTCS ASTM A420 WPL6 Buttweld Pipe Fittings through a worldwide network of stock-keeping branches. These Low Temperature ASTM A420 WPL6 Buttweld Fittings is use in various industries like :

  • LTCS WPL6 Buttweld Pipe Fitting uses in Oil and Gas Pipeline
  • ASTM A420 WPL6 Buttweld Pipe Fittings uses in Chemical Industry
  • Grade WPL6 LTCS Pipe Fittings uses in Plumbing
  • LTCS ASTM A420 WPL6 Buttweld Pipe Fittings uses in Heating
  • ASTM A420 WPL6 Pipe Fittings uses in Water Supply Systems
  • LTCS ASTM A420 WPL6 Buttweld Fittings uses in Power Plant
  • LTCS WPL6 Butt weld Pipe Fittings uses in Paper & Pulp Industry
  • WPL6 LTCS Buttweld Pipe Fittings uses in General Purpose Applications
  • ASME SA420 LTCS WPL6 Pipe Fittings uses in Fabrication Industry
  • LTCS WPL6 Buttweld Fittings uses in Food Processing Industry
  • Low Temperature WPL6 Buttweld Pipe Fittings uses in Structural Pipe
